ESS-BATT RE Series – High-Voltage Industrial Energy Storage (48–107 kWh)
The ESS-BATT RE Series delivers scalable high-voltage energy storage for commercial and industrial applications, offering flexible capacity from 48 kWh to 107 kWh and voltages between 384 V and 844.8 V. Engineered for reliable solar integration, peak shaving, backup power, and microgrid support, this LiFePO₄ battery system ensures efficient, cost-effective, and uninterrupted energy while enhancing long-term operational resilience for businesses.
Sustainable Living, Powered by BSLBATT
Empower Industrial Operations with ESS-BATT RE
The ESS-BATT RE Series from BSLBATT delivers modular high-voltage energy storage, with models RE5, RE7, RE9, and RE11 covering 384 V to 844.8 V. Built with LiFePO₄ cells and an advanced BMS, it ensures high safety, long cycle life, and flexible scalability, making it ideal for industrial and commercial energy storage solutions.
Modular & Scalable
The ESS-BATT RE Series uses 9.75 kWh modules, scalable from 48.8 kWh to 107.3 kWh, with parallel expansion up to megawatt-scale for flexible industrial and commercial energy storage.
Long Life & Fast Charging
The ESS-BATT RE Series delivers over 4,000 cycles at 80% DOD and 25°C, with 1C charge/discharge rates for reliable, high-performance industrial energy use.
Smart & Safe
The ESS-BATT RE Series features an advanced BMS with over-voltage, over-temperature, and short-circuit protection for safe, stable operation in demanding environments.
Compact & Efficient
The ESS-BATT RE Series uses high-energy-density cells and a compact design, saving up to 30% space for efficient indoor installations.
Wide Range & Durable
The ESS-BATT RE Series operates from -20°C to 55°C with 15–90% RH, delivering stable performance in diverse indoor environments.
Flexible Integration
The ESS-BATT RE Series supports CAN and ModBus, allowing seamless integration with energy management systems for remote monitoring and smart control.
Specifications
Discover ESS-BATT RE Series Performance
The ESS-BATT RE Series delivers modular high-voltage LiFePO₄ energy storage for industrial and commercial applications, with scalable capacities from 48 kWh to 107 kWh. Designed for high reliability, long cycle life, and safe, stable operation, it supports solar integration, backup power, peak shaving, and microgrid solutions. This flexible system ensures efficient, uninterrupted energy while optimizing operational costs and reducing reliance on the grid.
| Parameter | Details |
|---|---|
| Cell Capacity | 3.2V / 127Ah |
| Cell Chemistry | Lithium Iron Phosphate (LiFePO4) |
| Rated Voltage | 76.8V |
| Rated Energy | 9.753kWh |
| Weight (Single Pack) | 70Kg ±3% |
| Dimension (H × W × D) | 135 × 740 × 645 mm |
| Number of Packs | 5 |
| System Rated Voltage | 384V |
| Operating Voltage Range | 336V – 432V |
| Recommended Voltage Range | 348V – 420V |
| Rated Charge/Discharge Current | 42.4A |
| System Rated Energy | 48.768kWh |
| Cycle Life | Fast Charge Cycles >4000 (80% DOD @ 25°C) |
| Operating Temperature | -20℃ ~ 55℃ |
| Operating Humidity | 15% – 90% RH (Non-condensing) |
| Installation Environment | Indoor |
| Fire Protection (Pack) | Optional |
| Communication Protocol | CAN / ModBus |
| Ingress Protection (IP) | IP20 |
| Dimension (L × W × H) | 1140 × 764 × 740 mm |
| Weight (Total Cluster) | 420Kg ±3% |
| Parameter | Details |
|---|---|
| Cell Capacity | 3.2V / 127Ah |
| Cell Chemistry | Lithium Iron Phosphate (LiFePO4) |
| Rated Voltage | 76.8V |
| Rated Energy | 9.753kWh |
| Weight (Single Pack) | 70Kg ±3% |
| Dimension (H × W × D) | 135 × 740 × 645 mm |
| Number of Packs | 7 |
| System Rated Voltage | 537.6V |
| Operating Voltage Range | 470.4V – 608.8V |
| Recommended Voltage Range | 487.2V – 588V |
| Rated Charge/Discharge Current | 42.4A |
| System Rated Energy | 68.275kWh |
| Cycle Life | Fast Charge Cycles >4000 (80% DOD @ 25°C) |
| Operating Temperature | -20℃ ~ 55℃ |
| Operating Humidity | 15% – 90% RH (Non-condensing) |
| Installation Environment | Indoor |
| Fire Protection (Pack) | Optional |
| Communication Protocol | CAN / ModBus |
| Ingress Protection (IP) | IP20 |
| Dimension (L × W × H) | 1440 × 764 × 740 mm |
| Weight (Total Cluster) | 560Kg ±3% |
| Parameter | Details |
|---|---|
| Cell Capacity | 3.2V / 127Ah |
| Cell Chemistry | Lithium Iron Phosphate (LiFePO4) |
| Rated Voltage | 76.8V |
| Rated Energy | 9.753kWh |
| Weight (Single Pack) | 70Kg ±3% |
| Dimension (H × W × D) | 135 × 740 × 645 mm |
| Number of Packs | 9 |
| System Rated Voltage | 691.2V |
| Operating Voltage Range | 604.8V – 777.6V |
| Recommended Voltage Range | 626.4V – 756V |
| Rated Charge/Discharge Current | 42.4A |
| System Rated Energy | 87.782kWh |
| Cycle Life | Fast Charge Cycles >4000 (80% DOD @ 25°C) |
| Operating Temperature | -20℃ ~ 55℃ |
| Operating Humidity | 15% – 90% RH (Non-condensing) |
| Installation Environment | Indoor |
| Fire Protection (Pack) | Optional |
| Communication Protocol | CAN / ModBus |
| Ingress Protection (IP) | IP20 |
| Dimension (L × W × H) | 1740 × 764 × 740 mm |
| Weight (Total Cluster) | 700Kg ±3% |
| Parameter | Details |
|---|---|
| Cell Capacity | 3.2V / 127Ah |
| Cell Chemistry | Lithium Iron Phosphate (LiFePO4) |
| Rated Voltage | 76.8V |
| Rated Energy | 9.753kWh |
| Weight (Single Pack) | 70Kg ±3% |
| Dimension (H × W × D) | 135 × 740 × 645 mm |
| Number of Packs | 11 |
| System Rated Voltage | 844.8V |
| Operating Voltage Range | 739.2V – 950.4V |
| Recommended Voltage Range | 765.6V – 924V |
| Rated Charge/Discharge Current | 42.4A |
| System Rated Energy | 107.289kWh |
| Cycle Life | Fast Charge Cycles >4000 (80% DOD @ 25°C) |
| Operating Temperature | -20℃ ~ 55℃ |
| Operating Humidity | 15% – 90% RH (Non-condensing) |
| Installation Environment | Indoor |
| Fire Protection (Pack) | Optional |
| Communication Protocol | CAN / ModBus |
| Ingress Protection (IP) | IP20 |
| Dimension (L × W × H) | 2040 × 764 × 740 mm |
| Weight (Total Cluster) | 840Kg ±3% |
